ANSI/BIFMA X5.4 - 2012: Lounge and Public Seating
時間：2020-09-17 訪問量：8401
| Edition: 20200621 更新 | ||||||||
| Section | Section Description | Summary of important content | 重要內容摘要 | |||||
| 1 | Scope | 1. This standard does not address general-purpose or task-oriented office chairs, or seating used for stadiums, auditoriums, lecture rooms, airports/train stations and similar high-use public seating areas. 2. The CAESAR anthropometric database (2002 report), which indicates the 95th percentile male weighs 253 pounds, was used in the development of the tests. 3. The tests were developed with an estimated product life of ten years based on continuous single-shift usage. 4. ISO 17025 requirements for reporting uncertainty do not apply when determining conformance to this standard. | 1. 本標準不適用于一般用途或以任務特定要求為導向的辦公椅，也不適用于體育場、禮堂、演講廳、機場/火車站和類似的高使用率公共座椅。 2. “CAESAR”人體測量數據庫(2002年報告)顯示，95%的男性體重為253磅，該數據被本標準引用。 3. 本標準的參數是按照產品壽命估計為10年來規劃的。 4. 本標準的不確定度要求不適合ISO 17025。 | |||||
| 2 | Definitions | / | / | |||||
| 3 | General | In order for measurements to be "universally" acceptable,only Chair Measuring Devices (CMD) built to BIFMA specifications may be used. | 為了使測量數據能夠被廣泛接受，本標準只認可用符合BIFMA規范的座椅測量裝置(即CMD)測量所得的數據。 | |||||
| 4 | Classification and Applicable Tests | |||||||
| Section | Section Desc | 章節內容 | KW Model | KW Model Desc | 儀器名稱 | 圖片 | 資料下載 | 操作視頻 |
| 1 | Scope | 范圍 | / | / | / | / | ||
| 2 | Definitions | 定義 | / | / | / | / | ||
| 2.5 | CMD | 美標坐具尺寸測量加載治具 | KW-BFM-01 | BIFMA Chair Measuring Device （CMD） | 美標坐具尺寸測量加載治具(俗名：BIFMA CMD) |  |  | |
| KW-BSE-60 | ISO CMD | ISO CMD |  | |  | |||
| 2.9 | Form-fitting load distribution device | 靠背加載墊 | KW-BFM-03 | Chair Back Form-fitting Device | BIFMA坐具靠背加載墊 |  | | |
| 5 | Backrest Strength Test - Horizontal - Static | 靠背水平靜載強度試驗。 | KW-BFM-38-4 | BIFMA sofa tester | 美標BIFMA沙發測試機 |  | | |
| 6 | Backrest Strength Test - Vertical - Static | 靠背垂直靜載強度試驗 | KW-BFM-38-4 | BIFMA sofa tester | 美標BIFMA沙發測試機 |
|
| |
| 7 | Backrest Strength Test - Horizontal - Cyclic | 靠背水平耐久測試 | KW-BFM-38-4 | BIFMA sofa tester | 美標BIFMA沙發測試機 |
|
| |
| 8 | Backrest Strength Test - Vertical - Cyclic | 靠背垂直耐久測試 | KW-BFM-38-4 | BIFMA sofa tester | 美標BIFMA沙發測試機 |
|
| |
| 9 | Arm Strength Test - Horizontal - Static | 扶手水平靜載強度測試 | KW-BFM-55-SD | Manual loading mechanism with force display | 手動加載和力顯示組件 |  | | |
| 10 | Arm Strength Test - Vertical - Static | 扶手垂直靜載強度測試 | KW-BFM-38-4 | BIFMA sofa tester | 美標BIFMA沙發測試機 |
|
| |
| 11 | Arm Durability Test for Multiple Seat Units - Horizontal - Cyclic | 多座位扶手水平耐久測試 | KW-BFM-38-4 | BIFMA sofa tester | 美標BIFMA沙發測試機 |
|
| |
| 12 | Arm Durability Test for Multiple Seat Units - Vertical - Cyclic | 多座位扶手垂直耐久測試 | KW-BFM-38-4 | BIFMA sofa tester | 美標BIFMA沙發測試機 |
|
| |
| 13 | Arm Durability Test for Single Seat Units - Angular - Cyclic | 單座位扶手耐久測試 | KW-BSE-16 | Arm rest tester | 坐具扶手試驗機 |  |
| |
| 14 | Seat Durability Test - Cyclic | 坐具座面沖擊耐久測試 | KW-BFM-11 | Seating Impact Tester | 坐具座面沖擊測試機 |
|
| |
| KW-BFM-02-BFM | Seating impact bag | 直徑16寸沖擊試驗砂袋 |
|
| ||||
| 15 | Drop Test - Dynamic | 坐具座面沖擊強度測試 | KW-BFM-11 | Seating Impact Tester | 坐具座面沖擊測試機 |
|
| |
| KW-BFM-02-BFM | Seating impact bag | 直徑16寸沖擊試驗砂袋 |
|
| ||||
| 16 | Leg strength Test - Front and Side Application | （沙發）腿正面和側面強度測試 | KW-BFM-55-SD | Manual loading mechanism with force display | 手動加載和力顯示組件 |
|
| |
| 17 | Unit Drop Test | 產品跌落測試 | N/A | N/A | N/A | |||
| 18.1 | Caster/Unit Base Durability Test - Cyclic | 五個位的腳輪耐久測試 | KW-BFM-17-1 | One-station Chair caster durablity tester | 單工位椅子腳輪耐久測試機 |
|
| |
| KW-BFM-17-2 | Two-stations Chair caster durablity tester | 雙工位椅子腳輪耐久測試機 |
|
| ||||
| KW-BFM-17-4 | Four-stations Chair caster durablity tester | 四工位椅子腳輪耐久測試機 |
|
| ||||
| 18.2 | Caster/Unit Frame Durability Test for Units with Legs - Cyclic | 四個位的腳輪耐久測試 | KW-BFM-17-1 | One-station Chair caster durablity tester | 單工位椅子腳輪耐久測試機 |
|
| |
| KW-BFM-17-2 | Two-stations Chair caster durablity tester | 雙工位椅子腳輪耐久測試機 |
|
| ||||
| KW-BFM-17-4 | Four-stations Chair caster durablity tester | 四工位椅子腳輪耐久測試機 |
|
| ||||
| 19 | Swivel Test - Cyclic | 旋轉耐久測試 | KW-BFM-09 | Chair swival test rig | 椅子旋轉耐久測試機 |
|
| |
| 20 | Tilt Meachnism Test - Cyclic | 后傾機構耐久測試 | KW-BFM-10-BP | Chair backrest tester for BIFMA - Back pull | 椅子靠背耐久測試機-后拉式 |
|
| |
| 21.4 | Rear Stability for Tilting Units | 后穩定性的傾斜單位 | KW-BFM-05-MS | Chair Rear Stability Test Disc | 坐具后穩定性測試加載模塊 |
|
| |
| KW-CHP-83-FGC | Digital force guage | 電子推拉力計 |
|
| ||||
| KW-BFM-05-PP | Support PP sheet for reclining seat of back rest stability testing | 具有靠背后傾機構的坐具后穩定性測試加載塑膠膜片 |
|
| ||||
| 21.5 | Front Stability Test | 前穩定性測試 | KW-CHP-83-FGC | Digital force guage | 電子推拉力計 |  |
| |
| 22 | Tablet Arm Load Ease Test - Cyclic | 寫字板（垂直）耐久測試 | KW-BFM-38-4 | BIFMA sofa tester | 美標BIFMA沙發測試機 |
|
| |
| KW-BFM-54 | Load pad for BIFMA tablet | 直徑8寸加載墊 | ||||||
| 23 | Tablet Arm Load Test - Static | 寫字板（垂直）強度測試 | KW-BFM-38-4 | BIFMA sofa tester | 美標BIFMA沙發測試機 |
|
| |
| KW-BFM-54 | Load pad for BIFMA tablet | 直徑8寸加載墊 | ||||||
| Appendix A | Impact Test Bag Construction | 座面沖擊試驗袋 | KW-BFM-02-BFM | Seating impact bag | 直徑16寸沖擊試驗砂袋 |
|
| |
| Appendix B | Stability Disk - Construction Details | 后穩定加載盤 | KW-BFM-05-MS | Chair Rear Stability Test Disc | 坐具后穩定性測試加載模塊 |
|
| |
| 特別備注 | 1. 本資料版權和最終解釋權屬東莞市錦輝檢測設備制造有限公司所有。 2. 為引導用戶快速完整的了解標準對應的各項檢測設備，上表中僅列出的測試項目對應的設備，并未包含相關加載墊和治具。 3. 同一設備配套不同的加載墊和治具可以滿足不同的測試要求。因此，如客戶需要，我們會在充分了解客戶的產品類別和具體需求后，給出我們的詳細配套方案。方案中將列出設備的詳細配置，包括加載墊和治具和各自的數量及價格； | |||||||
